How To Tile A Niche

June 11, 2025

how to tile a niche Learning how to tile a niche in your bathroom can transform a simple shower into a stylish and functional space. Not only does tiling add aesthetic appeal, but it also enhances the durability and waterproofing of the niche area, making it a practical choice for homeowners. Whether you're a DIY novice or a seasoned renovator, understanding the right materials, tools, and techniques is crucial for a successful tiling project. Below is a helpful table to guide you through the essential steps and materials needed for tiling a niche.

Step Materials Tools
1. Measure & Plan Measurement tape, Level Pencil, Ruler
2. Prepare Surface Waterproof membrane, Primer Paintbrush, Roller
3. Install Tiles Tiles, Tile adhesive Notched trowel, Tile spacers
4. Grout & Seal Grout, Sealer Grout float, Sponge

Getting Started: Measure & Plan

Abstract image of blue tiled pool edges with water ripples, exuding a minimalist and calming vibe.

Diving into a tiling project can be both exciting and daunting, but it all kicks off with accurate measurements. Never underestimate the power of a good plan. Start by using your measurement tape to determine the exact dimensions of the niche. This sets the stage for the entire project. A level is your best friend here; it ensures everything aligns perfectly, which is crucial for a smooth, professional look. Once you have your measurements, grab that pencil and ruler to sketch out your plan. This blueprint will guide you through, helping you visualize the finished product and streamline the workflow.

Uniform tiling 44-t0
"Uniform tiling 44-t0" by Blackcoffee Wik is licensed under CC BY-SA 4.0. .

Preparing the Surface

Before you start laying tiles, preparing the surface is a step you can't skip—it’s the secret sauce for a lasting tile job. First, apply a waterproof membrane to protect the underlying structure from moisture, a step especially crucial in a bathroom setting. Primer follows, providing a solid base for the adhesive to grip onto. Use a paintbrush or roller to apply these materials, ensuring even coverage across the entire surface. A well-prepared surface is the canvas upon which your tiling masterpiece will rest, so take your time and do it right.

niche medor
"niche medor" by pilllpat (agence eureka) is licensed under CC BY 2.0. .

Installing Tiles Like a Pro

Armed with your notched trowel and tile adhesive, it's time to bring your design to life. Spread the adhesive evenly across small sections at a time to prevent it from drying before you set the tiles. Place each tile carefully, using tile spacers to maintain consistent gaps for grouting later. Pay attention to the patterns, especially around corners and edges—these are often the areas that make or break the visual appeal of the niche. For more guidance on choosing the best materials, check out the best shower ceiling tiles for your bathroom renovation. Patience is key here; a rushed job can lead to uneven tiles and a less-than-perfect finish.

Grouting & Sealing: The Finishing Touch

With the tiles in place, it’s time to grout. Mix your grout to a consistency similar to peanut butter; this makes it easier to work with. Apply it using a grout float, ensuring it fills all the spaces between the tiles. After it sets, use a damp sponge to wipe off excess grout, revealing clean, defined lines. The final step is sealing—an essential process to protect your tiles from water damage and staining over time. A clear sealer applied with precision will keep your niche looking fresh and new.

By following these steps, your niche not only serves as a functional storage solution but also becomes a stunning feature in your bathroom. Ready to transform your space with a personal touch? Share your progress and any tips or challenges you've encountered along the way in the comments below. We’d love to hear your stories and see your beautiful results!

For more insights and inspiration, explore our recent articles and content.

Recommended Video Tutorial

Learning how to tile a niche in your bathroom can transform a simple shower into a stylish and functional space. To help you achieve this, check out the video "Shower Niche Tile Tips for Beginners" by Home Repair Tutor, which offers practical guidance on tiling a shower niche with subway tiles.

What order do you tile a niche?

Tiling a shower niche in the right sequence helps prevent leaks, simplifies alignment, and creates a clean, professional appearance. Here’s an expert-approved method for installing a shower niche without relying on bullnose tile:

1. Preparing the Job: Ensure your shower niche and surrounding walls are waterproofed. Gather all essential tools and materials—tiles, thinset, trowels, and spacers—so you’re ready to work efficiently.
2. Step 1: Selecting Your Trowel: Match your trowel size to your tile’s dimensions for an even spread of thinset and a good bond.
3. Step 2: Choose the Sill Tile: Pick a durable tile that will form the niche’s base, often referred to as the sill. This tile should slope slightly toward the shower for proper drainage.
4. Step 3: Apply the Thinset: Use your trowel to evenly comb thinset on the niche’s base. Avoid air pockets or uneven patches.
5. Step 4: Place the Sill Tile: Set the sill tile in place, gently pressing it into the thinset and checking it with a level.
6. Step 5: Apply the Back Wall Tiling: Move on to the niche’s back wall. Start from the bottom and work your way up. A laser level or spirit level helps keep tiles aligned.
7. Step 6: Apply the Ceiling Tiles: If your niche design includes a top or “ceiling,” use thinset and position these tiles overhead, ensuring a snug fit.
8. Step 7: Prepare and Install the Side Tiles: Finally, measure and cut the side tiles. Apply thinset, press them firmly in place, and double-check with a level to confirm alignment.

Should a shower niche be grouted or caulked?

In shower niches, grout seals the space between tiles, but corners and transition areas need caulk for extra flexibility and protection. Caulking those joints helps prevent cracks caused by movement or settling over time. Once grout and caulk are fully cured (usually about 72 hours), apply a quality sealer to shield the niche from water damage and keep it looking fresh.

What tile to use for niche?

Choosing between full-size tiles and mosaics depends on both your personal style and the complexity of your niche. Larger tiles often look sleek and modern, while mosaic tiles adapt to corners and angles more easily. Regardless of your choice, select materials rated for moisture exposure, ensure proper waterproofing, and keep the overall style of your shower in mind for a cohesive design.

How to tile a plastic niche?

A plastic shower niche can be a convenient option, but correct installation is key to preventing water damage. Here’s a straightforward process:

1. Step 1: Choosing Your Trowel: Select a trowel size that suits your tile thickness for solid thinset coverage.
2. Step 2: Add the Sill: Fit a slightly sloped sill tile to direct water away from the niche interior.
3. Step 3: Comb Thin-Set on Niche Back Wall: Apply an even layer of thinset, avoiding ridges or gaps.
4. Step 4: Backbutter the Sill Tile: Spread thinset on the back of the sill tile for extra adhesion.
5. Step 5: Add Tile to Sill: Press the tile firmly into place and confirm it slopes downward for drainage.
6. Step 6: Laser Level the Sill: Use a laser level (or spirit level) to make sure the sill sits perfectly flat and level side to side.
7. Step 7: Make the Sill Proud: Raise the front edge slightly so water naturally runs off.
8. Step 8: Level Each Sill: Double-check your work to keep all tiles aligned, secure, and ready for daily use.

Tiling a niche isn't just about practicality—it's about expressing your unique style in a way that's both functional and fabulous. Whether you opt for monochromatic elegance or a pop of color to brighten up your mornings, the choices are as varied as your imagination. Remember, the key to a successful tiling project is all in the preparation and patience during installation. Once you've laid that last tile, you can step back and admire a bespoke masterpiece that you've brought to life with your own hands. It’s an incredibly satisfying experience that not only adds value to your home but also gives you a personal spa-like retreat to enjoy every day.
